| Water Solutions for the Oil & Gas Industry | ||||
|---|---|---|---|---|
|
Siemens Water Solutions addresses water and wastewater needs of the oil & gas industry with a portfolio that includes physical and chemical separation, biological treatment, and complex hydrothermal technologies. We bring years of expertise and experience coupled with a technology portfolio and the ability to fully integrate the supply, from simple products to complete solutions, managing customer risk in execution and process performance. Water is a resource and a byproduct of all that we do – a critical element in offshore, onshore, upstream and downstream activities. The treatment and management of this water is becoming increasingly complex as you work to keep pace with global standards, energy demand and environmental regulations. Rely on us to be your water solutions partner. Together, we’ll make real what matters most. Our core business is processing and treating water and wastewater for companies like yours. Our oil and gas business includes water treatment technologies, total water treatment solutions and water treatment services. We address your specific needs, from simple products to complex, fully integrated solutions, from beginning to end. |
||||
 |
 |
 |
||
| Water Solutions Brochure | Siemens: Deeply Reliable, Across The Entire Oil & Gas Value Chain | Proven Returns For Tank Farms And Terminals | ||
Oily water filtration was developed for filtering free oil and suspended solids from produced water or refinery wastewater, to be disposed of, re-injected, discharged or reused. These systems primarily used black walnut shell media, and required expensive treatment upstream to limit the filter loading rate.
Siemens’ Revive™ oily water membrane systems replace both filtration and flotation with a single step, eliminating the need for polymers and allowing for better oil recovery. Revive™ systems can achieve Oil & Grease and Total Suspended Solids levels of <1 mg/L, and Silt Density Index of <3.
Corrugated Plate Separators (CPS’s) provide economical and effective removal of oil and solids from wastewater by gravity, in a smooth, efficient automatic flow. With thousands of installations in operation, this proven design has no moving parts and provides consistent operating results for simple and better separation.
The Folded Flow® DAF system’s simple and innovative design “folds” the flow by removing effluent from the same end of the tank as the influent is introduced, resulting in a higher hydraulic loading rate.
Hydrocell™ hydraulic induced air flotation separators remove oil and suspended solids from water in large volumes, and can process solids and oils from 50 ppm to several hundred ppm with product effluents containing less than 5 ppm.
The PACT system combines biological treatment and carbon adsorption into a single, synergistic treatment step, resulting in significant cost savings and performance advantages over other systems.
Siemens Water Solutions offers a complete line of products to remove oily contaminants from water. Our newest addition to this line of products is the Monosep high-flow walnut shell filter, offering improved technology in walnut shell filtration.
The patented Veirsep horizontal flotation system incorporates several unique technologies to separate oil and various other contaminates from produced water and contaminated wastewater streams.
The Spinsep vertical flotation system incorporates several unique methods for removing oil from produced and wastewater streams before they are discharged or injected.
Siemens’ industry-leading Brise™ bubble generating pump technology has been enhancing flotation systems in the Oil & Gas industry for over 20 years.
And now, our new Brise™ 2.0 pump continues – and improves – that tradition of superior flotation performance, and helps save you money, in an ever-changing oil production market.
Our patented Combosep (COMBination Of SEParators) is typically comprised of a vertical and horizontal flotation system, mounted on a common skid, complete with interconnect piping.
The high efficiency liquid/liquid hydrocyclone provides maximum oil/water separation efficiency, and is used in industrial process water, industrial reuse, oil/water separation, and clarification/separation applications
This filter uses variations of different medias in a downflow pressure filter configuration. The flux varies with different applications and can range from 5 GPM/ft² for some mining applications to 20 GPM/ft² for offshore seawater filtration
Zimpro Wet Air Oxidation (WAO) systems are used primarily for treatment of high strength industrial wastewater streams.
API Oil/Water Separators are the performance, safety and environmental standard for petroleum refineries throughout the world
Auto-Shell walnut shell filters remove oily contaminants from water, and are used in treating oilfield produced water, refinery wastewater, steel mill direct spray and caster water, ethylene plant quench water, copper concentrate decant and cooling water
From biological and oily water treatment to the treatment of high-strength, complex wastewaters, Siemens Water Solutions brings years of proven expertise and real-world experience—allowing us to help you manage risk while achieving operational performance goals. We also offer comprehensive feasibility and pilot studies, in addition to complete aftermarket services. Download our new downstream capabilities brochure today.
Produced water is generated in the process of lifting oil and gas from water-bearing formations–typically sea or lake beds. As oil and gas is lifted to the surface, water is brought along with it. This water must be treated prior to discharge or re-injection.
Meeting water quality specifications for injection or reinjection is essential for protecting the permeability of a reservoir.
The treatment of process water can have a substantial and serious impact on a facility’s bottom line results in the short term as well as over the life of the equipment.
In the last 10 years, we have successfully installed over two dozen spent caustic wet oxidation systems, with capacities varying from 0.5 to 18.5 m3/h (2 to 81 gpm). Our systems are the industry standard and are included in many of the new world-scale ethylene plants.
Siemens Energy, Inc. - Water Solutions
301 West Military Road
Rothschild, WI 54474
UNITED STATES
Phone: 715-359-7211
Jiujiang, a city of 5 million people, borders the edge of the Yangtze River as well as Poyang Lake, each China’s largest. To the east of the city’s residential districts, midway on a peninsula separating the two bodies of water, sits the giant petrochemical complex of the Sinopec Jiujiang Company, a subsidiary of the Sinopec Corporation, the nation’s largest refiner. Nearly 3,000 people work there.
Herman Coello, Siemens, USA, discusses automation solutions that optimize the efficiency of utilizing native Texas sand for fraccing.
Ever since Coriolis flow measurement technology achieved mainstream appeal, industry has been fervently striving to take advantage of its benefits. And while Coriolis is clearly a highly advantageous solution for many crucial flow measurement applications, it is not without flaw.
Since the first Coriolis flow sensors were introduced to the marketplace in the 1970s, the technology has evolved considerably. As the installed base for Coriolis grew, the sensors were being called upon to deliver data in environments with increasing levels of complexity. This meant that Coriolis sensors had to adapt and conform to a dizzying array of ever-changing installation requirements, process conditions, communication formats, and configuration parameters. The following article highlights four key advances in Coriolis flow measurement’s journey from the 1970s to today.
Coriolis measurement has been adopted as a default technology in many application scenarios due to its high accuracy and immunity to process variables (temperature, pressure and flow profile). However, Coriolis wasn't always widely accepted. Two applications, in particular, helped what was once a nascent flow measurement technology gain a foothold in the marketplace.
There is no doubt that the practice of hydraulic fracturing, also known as fracking, has completely changed the oil and gas landscape in recent history. There is also no doubt that this is a highly technical process.
It may not be immediately apparent just how crucial bubbles are to oil and gas operations. They play a critical role in a process known as dissolved gas flotation (DGF), which is imperative for removing contaminants. And not all bubbles are created the same.
Horizontal drilling started back in 1929 and hydraulic fracking began in 1949. However, it was not until 2003 that the horizontal drilling and hydraulic fracking processes were combined to extract gas from the Barnett Shale in north Texas. Since then, gas drilling has increased by 14 times in the United States. Given the vast shale formations throughout the United States, drilling will continue to increase for several more years.
Jack Roushey, Product Manager for Siemens electromagnetic flowmeters, presents on how to use magmeters in zero upstream and zero downstream applications. Based on their demonstrated ability to perform in non-ideal conditions, the SITRANS F M MAG 5100W and MAG 8000 electromagnetic sensors from Siemens have received approval for 2% accuracy custody transfer (MI-001) and non-custody transfer applications for installation with zero diameter upstream pipe and zero diameter downstream straight run pipe from the sensor.
Braskem Idesa is a 75-25 joint venture between Brazil’s Braskem, the largest producer of thermoplastic resins in the Americas, and Grupo Idesa, a traditional petrochemical company in Mexico. As one of the project’s top suppliers of skills, technology and equipment, Siemens itself marshaled resources and employees from 11 different countries to collaborate on a truly multinational and multicultural level with Braskem Idesa and its global partners.
Manual tank gauging is a common oilfield activity that’s resulted in multiple worker deaths in recent years. By using work practice control, operators can reduce the risks it poses significantly.
PerforMedia™ oil removal media replaces walnut shells in media filtration systems. Manufactured from materials not subject to agricultural limitations, the media is able to handle five times the amount of oil before requiring backwash; is able to maintain feed concentrations of greater than 500 mg/L while producing effluent well under 10 ppm; and can be used on a wide range of oil API and elevated temperatures. Download our white paper today.
Siemens Water Solutions offers a full range of laboratory scale, bench scale and pilot scale testing capabilities – either at our site or at yours. Let us pilot test a system for you today and demonstrate the benefits of a PACT® MBR system for you in real time.
Streamlined oil and gas wastewater treatment via the unique, all-in-one PACT® MBR system by Siemens — proven, available and supported worldwide — uses half the space of conventional methods and offers substantial cost savings. The PACT® MBR system combines the process performance of activated sludge biological treatment, activated carbon adsorption and membrane filtration into a simplified and compact waste treatment model.
